Used 2019 HOMAG Homag S200 | Edgebander / Plaquese de Chant

Description

Technical Specifications:

016″ to 1/8″ maximum edgebanding thickness capacity (coil or strip)

Edgeband length: strips 9" minimum 5/16" min. to 2" max. panel thickness

Minimum panel length: 5-1/2"

Minimum panel width: 2-3/4"

Edgeband height: 5/16 to 1-5/8"

Electronic Easy Control with backlit LCD display

(2) 1 HP 12 000 RPM pre-milling units with diamond cutterheads

Automatic magazine for strip and coil feeding

Hot melt glue pot with 12 minute heat up time

Automatic temperature reduction feature (lowers the glue temperature if no panel is run over a 15 minute span)

Guillotine for cutting up to 3 mm PVC from the coil

Pressure station with (1) motorized pressure roller plus (2) additional idle pressure roller with digital setting system

Premill with (2) 100mm heads

1/4 HP 12 000 RPM double motor end trim .33 HP

12 000 RPM top and bottom trim station equipped with two DFC combination straight/radius cutter heads and digital readouts (three different working positions: flush trim trimming with overhang and radius/bevel trimming)

Top and bottom profile quick change scraping unit

1-speed feed with speed of 26 FPM

Digital on top pressure beam for height indication

Adjustable infeed fence with digital readout Automatic height adjustment with top pressure beam for all work stations

Digitals on top and bottom trim station

Dust extraction: (4) 80 mm outlets and (1) 100 mm outlet 1600 CFM required

Compressed air connection: 6 bar (85 psi) Isolation transformer with variable infeed voltage for balancing all 3 phases of incoming power

Machine Weight: 1 650 lbs.

Machine dimensions: 12'1" long x 4' wide

Amperage required @ 230 volt: 30 amps
