Used HEESEMANN HSM.2 DB-2 Planetary 2 Head Sander | Sableueses / Sanders

Description

Head 1: DB-S Head – Rotating Planetary Sanding Unit
Heesemann's rotating planetary sanding unit incorporates sanding discs for the purpose of smoothing the work surface, breaking edges, seal sanding and texturing. This head includes:

· 10 driven discs with quick changing device

· Rotation in both directions

· Central height adjustment

· 7.5 kW (10 Hp) motor to power the discs

· 1.5 kW (2 Hp) motor gear box

· Brush trimming: Flex Trim

· Tool Diameter: 150 mm (6”)

· Other brush discs available on demand

· One set of discs is included with sanding head

Head 2: DB-S Head – Rotating Planetary Sanding Unit
Heesemann's rotating planetary sanding unit incorporates sanding discs for the purpose of smoothing the work surface, breaking edges, seal sanding and texturing. This head includes:

· 10 driven discs with quick changing device

· Rotation in both directions

· Central height adjustment

· 7.5 kW (10 Hp) motor to power the discs

· 1.5 kW (2 Hp) motor gear box

· Brush trimming: Flex Trim

· Tool Diameter: 150 mm (6”)

· Other brush discs available on demand

· One set of discs is included with sanding head

Press-on Rollers Before and after Sanding Heads

A 50 mm roller at the infeed and outfeed of the sanding head helps to hold down workpieces – particularly parts with very little surface area (i.e. face frames)

· spring loaded and adjustable

· Distance between rollers approx.. 500mm (20”)

Workpiece Blasting Device
Rotating compressed air nozzles for blasting workpiece surface. Operate only if a workpiece is present to preserve compressed air. Keeps the conveyor belt clean and helps clean dust out of profiled surfaces (such as center panels on 5 piece doors) – so parts leave clean and ready to move onto next process

Technical Specifications

Working height: 880 mm (36.2")

Workpiece thickness: 3 mm to 160 mm (0.118" to 6.29")

Working width: 1300 mm (51.2")

Transport belt speed: 3 mpm to 15 mpm (10 fpm to 49 fpm)

Sanding belt access: Left hand

Operators side: Left hand

Voltage: 480 Volts, 3 Phase, 60 HZ (24 V controls)

Full load amps: Approx. 100 amps at 480 Volts

Compressed air: ~25 cfm @ 100 psi

Dust extraction: ~4000 CFM
